EDC15C2 0281010766 1037353612 ORI – original full BDM backup from a Bosch EDC15C2 fitted to the Citroën Xsara 2.0 HDi (PSA 9643526080): external flash 512 KB + EEPROM 95080 (1 KB), bench read, nothing modified.
What you get (ZIP, 403 KB)
✔ EDC15C2 0281010766 1037353612 ORI full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC15C2 used in the Citroën Xsara 2.0 HDi: external flash 512 KB + EEPROM 95080 (1 KB) from one and the same ECU, delivered as a ZIP with an INFOS.html datasheet.
A true full BDM, not a flash-only OBD read. Moreover, the ZIP is delivered instantly once the order is paid.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Status |
|---|---|---|
| Citroën Xsara | 2.0 HDi | confirmed for this software |
| Peugeot 406 | 2.2 HDi | confirmed for this software |
| Citroën Xsara Picasso | 2.0 HDi | reported, not confirmed |
Two Xsara with the same engine can carry different software, so match the numbers on the ECU label – HW 0281010766, PSA 9643526080 – and the software 1037353612 shown by your tool before ordering.
Archive contents
| File | Memory | Size |
|---|---|---|
0281010766_9643526080_SW1037353612_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010766_9643526080_SW1037353612_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Flash and EEPROM are from the same unit, so writing both gives a coherent ECU (immobiliser data of the donor car included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.
EDC15C2 0281010766 1037353612 ORI – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281010766 – printed 0 281 010 766 on the label |
| PSA part number | 9643526080 – printed 96 435 260 80 |
| Software (SW) | 1037353612 – also written SW1037353612 |
| Upgrade / SW upg. | none – your tool shows 1037353612 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 403 KB, instant download after payment |
Professionals call this kind of file a full BDM backup or an ORI file – in French fichier d’origine, in Italian file ori.
Notes on this file
This page covers one exact software: EDC15C2 0281010766 with SW 1037353612. Another number on your tool means another file – use the search or ask us.
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 010 766 and 96 435 260 80. The 1039S… sticker is not a software number – 1037353612 is only visible through a tool or in INFOS.html.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037353612 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037353612 again |
Expected ID screen: SW 1037353612, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281010766 1037353612 ORI a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Citroën Xsara 2.0 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037353612.
My tool shows SW 1037353612 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 010 766 and 96 435 260 80 on the label; if the upgrade line is empty or repeats 1037353612, this is your file.
Does it fit the Peugeot 406 2.2 HDi?
Yes – the 406 is confirmed for this software. Check 0 281 010 766 and 96 435 260 80 on the label and software 1037353612 in your tool before ordering.
Will this file work on a Citroën Xsara Picasso 2.0 HDi?
Only if the Xsara Picasso label reads HW 0281010766 / PSA 9643526080 and the tool shows 1037353612. It is reported with this software but we did not read it from a Xsara Picasso ourselves.
Does the EEPROM contain the immobiliser of the donor Xsara?
Yes, as read. This is the original state of ECU 0281010766, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
