EDC15C2 0281010550 1037353310 ORI: the unmodified full BDM backup of a Bosch EDC15C2 fitted to the Citroën Xsara 2.0 HDi (PSA 9641608480) – external flash 512 KB + EEPROM 95080 (1 KB) read on the bench.
What you get (ZIP, 395 KB)
✔ EDC15C2 0281010550 1037353310 ORI full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (395 KB) holding the software of a Bosch EDC15C2 read on the bench (Citroën Xsara 2.0 HDi application): external flash 512 KB + EEPROM 95080 (1 KB) from the same unit, with an INFOS.html datasheet.
In forum terms: a full BDM / full backup, flash and EEPROM together, not an OBD flash read. Also, the download opens as soon as the payment is confirmed.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Citroën Xsara | 2.0 HDi | RHY | 90 hp / 66 kW | confirmed for this software |
Two Xsara with the same engine can carry different software, so match the numbers on the ECU label – HW 0281010550, PSA 9641608480 – and the software 1037353310 shown by your tool before ordering.
Archive contents
| File | Memory | Size |
|---|---|---|
0281010550_9641608480_SW1037353310_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010550_9641608480_SW1037353310_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Because flash and EEPROM come from one ECU, writing both restores a coherent unit (donor immobiliser data included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.
EDC15C2 0281010550 1037353310 ORI – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281010550 – printed 0 281 010 550 on the label |
| PSA part number | 9641608480 – printed 96 416 084 80 |
| Software (SW) | 1037353310 – also written SW1037353310 |
| Upgrade / SW upg. | none – your tool shows 1037353310 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 395 KB, instant download after payment |
Tuners and forums call it a full backup, full BDM or original file; French-speaking customers say fichier d’origine, Italians file ori.
Notes on this file
Engine: Citroën Xsara 2.0 HDi (90 hp, engine code RHY).
Works with all common tools – KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases an alignment with a hex editor or WinOLS may be needed before writing. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 010 550 and 96 416 084 80. The 1039S… sticker is not a software number – 1037353310 is only visible through a tool or in INFOS.html.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037353310 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037353310 again |
Your tool should show 1037353310 as SW and either nothing or 1037353310 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281010550 1037353310 ORI a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Citroën Xsara 2.0 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037353310.
My tool shows SW 1037353310 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 010 550 and 96 416 084 80 on the label; if the upgrade line is empty or repeats 1037353310, this is your file.
Does the EEPROM contain the immobiliser of the donor Xsara?
Yes, as read. This is the original state of ECU 0281010550, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
