EDC15C2 0281010772 1037353609 ORI is the original full BDM backup of a Bosch EDC15C2 fitted to the Peugeot 406 2.2 HDi (PSA 9644199780): external flash 512 KB + EEPROM 95080 (1 KB), read on the bench and delivered unmodified.
What you get (ZIP, 402 KB)
✔ EDC15C2 0281010772 1037353609 ORI full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (402 KB) with the complete memory of a Bosch EDC15C2, read on the bench (Peugeot 406 2.2 HDi application): external flash 512 KB + EEPROM 95080 (1 KB), taken from the same ECU, plus an INFOS.html datasheet.
A true full BDM, not a flash-only OBD read. In addition, the download link is available right after payment.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Status |
|---|---|---|
| Peugeot 406 | 2.2 HDi | confirmed for this software |
Do not rely on the model alone: check HW 0281010772 and PSA 9644199780 on the label, then 1037353609 on the identification screen of your tool.
Archive contents
| File | Memory | Size |
|---|---|---|
0281010772_9644199780_SW1037353609_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010772_9644199780_SW1037353609_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Flash and EEPROM are from the same unit, so writing both gives a coherent ECU (immobiliser data of the donor car included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.
EDC15C2 0281010772 1037353609 ORI – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281010772 – printed 0 281 010 772 on the label |
| PSA part number | 9644199780 – printed 96 441 997 80 |
| Software (SW) | 1037353609 – also written SW1037353609 |
| Upgrade / SW upg. | none – your tool shows 1037353609 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 402 KB, instant download after payment |
In workshop language this is an ORI file or full BDM backup of the EDC15C2 (fichier d’origine in French, file ori in Italian).
Notes on this file
This page covers one exact software: EDC15C2 0281010772 with SW 1037353609. Another number on your tool means another file – use the search or ask us.
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC15C2 you will read 0 281 010 772 (hardware) and 96 441 997 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037353609 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037353609 again |
Your tool should show 1037353609 as SW and either nothing or 1037353609 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281010772 1037353609 ORI a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Peugeot 406 2.2 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037353609.
My tool shows SW 1037353609 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 010 772 and 96 441 997 80 on the label; if the upgrade line is empty or repeats 1037353609, this is your file.
Will this file work on a Peugeot 607?
Only if the 607 label reads HW 0281010772 / PSA 9644199780 and the tool shows 1037353609. It is reported with this software but we did not read it from a 607 ourselves.
Does the EEPROM contain the immobiliser of the donor 406?
Yes, as read. This is the original state of ECU 0281010772, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
