EDC16C34 0281013872 1037386166 1037501004 is the original full BDM backup of a Bosch EDC16C34 fitted to the Peugeot 308 1.6 HDi (PSA 9664843780): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read on the bench and delivered unmodified.
What you get (ZIP, 754 KB)
✔ EDC16C34 0281013872 1037386166 1037501004 full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (754 KB) holding the updated software of a Bosch EDC16C34 read on the bench (Peugeot 308 1.6 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from the same unit, with an INFOS.html datasheet.
Moreover, the ZIP is delivered instantly once the order is paid.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Years | Status |
|---|---|---|---|---|---|
| Peugeot 308 | 1.6 HDi | 9HT | 110 hp / 80 kW | — | confirmed for this software |
| Citroën Berlingo | 1.6 HDi | 9HV | 75 hp / 55 kW | — | reported, not confirmed |
| Citroën C4 | 1.6 HDi | 9HY | — | 2004-2010 | reported, not confirmed |
| Peugeot 207 | 1.4 HDi | — | — | — | reported, not confirmed |
| Peugeot 207 | 1.6 HDi | — | 110 hp / 80 kW | — | reported, not confirmed |
| Peugeot 307 | 1.6 HDi | — | 110 hp / 80 kW | — | reported, not confirmed |
| Peugeot 407 | 1.6 HDi | — | — | — | reported, not confirmed |
| Peugeot Partner | 1.6 HDi | 9HV | 75 hp / 55 kW | — | reported, not confirmed |
Two 308 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281013872, PSA 9664843780 – and the software 1037386166 shown by your tool before ordering.
If your 308 shows HW 0281013872 but SW 1039398220 (PSA 9664843780), you need this other file instead.
Archive contents
| File | Memory | Size |
|---|---|---|
0281013872_9664843780_SW1037386166_MJ1037501004_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281013872_9664843780_SW1037386166_MJ1037501004_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281013872_9664843780_SW1037386166_MJ1037501004_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281013872_9664843780_SW1037386166_MJ1037501004_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Multi-tool ready: the EEPROM comes in three formats (2 KB / 4 KB / 8 KB), same content. 2 KB is native; pick the size your tool asks for.
EDC16C34 0281013872 1037386166 1037501004 – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281013872 – printed 0 281 013 872 on the label |
| PSA part number | 9664843780 – printed 96 648 437 80 |
| Software (SW) | 1037386166 – also written SW1037386166 |
| Upgrade / SW upg. | 1037501004 – also written MJ1037501004; your tool shows SW 1037386166 and SW upg. 1037501004 |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 754 KB, instant download after payment |
Notes on this file
Hardware 0281013872 is known with 2 software versions in our catalogue; this page is 1037386166 updated to 1037501004. Engine: Peugeot 308 1.6 HDi (110 hp, engine code 9HT).
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 013 872 and 96 648 437 80. The 1039S… sticker is not a software number – 1037386166 is only visible through a tool or in INFOS.html.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037386166 |
| SW upg. (SW màj., soft up, UpgSW) | 1037501004 |
Two numbers = this file: SW 1037386166 and SW upg. 1037501004. One number 1037501004 alone = still this file. 1037386166 twice = the factory read, sold on its own page.
Other files you may need
| Version | Tool shows | Vehicle | File |
|---|---|---|---|
| 1037501004 | SW 1037386166 / SW upg. 1037501004 | 308 1.6 HDi | this file |
| upgrade 1037389534 | SW 1037386166 / SW upg. 1037389534 | 308 1.6 HDi | open |
| upgrade 1037389540 | SW 1037386166 / SW upg. 1037389540 | 308 1.6 HDi | open |
| upgrade 1037389545 | SW 1037386166 / SW upg. 1037389545 | 308 1.6 HDi | open |
| upgrade 1037389546 | SW 1037386166 / SW upg. 1037389546 | 308 1.6 HDi | open |
| upgrade 1037389547 | SW 1037386166 / SW upg. 1037389547 | 308 1.6 HDi | open |
- Same hardware 0281013872: SW 1039398220 (PSA 9664843780) – 308 1.6 HDi
- Other Peugeot 308 EDC16C34 files: 0281013871 · 1037383745 upg. 1037389514 · 0281011629 · 1037386166 upg. 1037395378 · 0281012985 · 1037386166 upg. 1039398234 · 0281013871 · 1037386178 upg. 1037389514 · 0281013871 · 1037386178 upg. 1037393468
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281013872 1037386166 1037501004 a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Peugeot 308 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037386166.
My tool shows SW 1037386166 and SW upg. 1037501004 – is this the file?
Yes, exactly this one: the flash holds the updated software 1037501004, and 1037386166 is the base number the ECU still reports.
My tool shows only “SW upg. 1037501004” and nothing else. Same file?
Yes. Some KESS versions fill only the upgrade field on an EDC16C34. Confirm 0281013872 and 9664843780 on the label and you are good.
Will this file work on a Citroën Berlingo 1.6 HDi?
Only if the Berlingo label reads HW 0281013872 / PSA 9664843780 and the tool shows 1037386166 / 1037501004. It is reported with this software but we did not read it from a Berlingo ourselves.
