EDC16C34 0281012982 1037383740 1037386162 is the original full BDM backup of a Bosch EDC16C34 fitted to the Citroën Jumpy 1.6 HDi (PSA 9663786880): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read on the bench and delivered unmodified.
What you get (ZIP, 685 KB)
✔ EDC16C34 0281012982 1037383740 1037386162 full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (685 KB) with the complete memory of a Bosch EDC16C34, read on the bench (Citroën Jumpy 1.6 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), taken from the same ECU, plus an INFOS.html datasheet.
Moreover, the ZIP is delivered instantly once the order is paid.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Citroën Jumpy | 1.6 HDi | 9HX | 90 hp / 66 kW | confirmed for this software |
| Fiat Scudo | 1.6 Multijet | 9HX | 90 hp / 66 kW | twin model – same vehicle as the Citroën Jumpy, Fiat badge |
| Fiat Scudo | — | 9HU | — | confirmed for this software |
| Peugeot Expert | 1.6 HDi | 9HU | 90 hp / 66 kW | twin model – same vehicle as the Citroën Jumpy, Peugeot badge |
| Fiat Scudo | 1.6 D | — | — | reported, not confirmed |
Two Jumpy with the same engine can carry different software, so match the numbers on the ECU label – HW 0281012982, PSA 9663786880 – and the software 1037383740 shown by your tool before ordering.
If your Jumpy shows HW 0281012982 but SW 1037386162 (PSA 9665091180), you need this other file instead.
Archive contents
| File | Memory | Size |
|---|---|---|
0281012982_9663786880_SW1037383740_MJ1037386162_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281012982_9663786880_SW1037383740_MJ1037386162_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281012982_9663786880_SW1037383740_MJ1037386162_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281012982_9663786880_SW1037383740_MJ1037386162_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
One EEPROM, three file formats (2 KB / 4 KB / 8 KB) so that every tool finds the size it expects – 2 KB is the chip itself, the content is identical.
EDC16C34 0281012982 1037383740 1037386162 – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281012982 – printed 0 281 012 982 on the label |
| PSA part number | 9663786880 – printed 96 637 868 80 |
| Software (SW) | 1037383740 – also written SW1037383740 |
| Upgrade / SW upg. | 1037386162 – also written MJ1037386162; your tool shows SW 1037383740 and SW upg. 1037386162 |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 685 KB, instant download after payment |
Notes on this file
Hardware 0281012982 is known with 2 software versions in our catalogue; this page is 1037383740 updated to 1037386162. Engine: Citroën Jumpy 1.6 HDi (90 hp, engine code 9HX).
Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC16C34 you will read 0 281 012 982 (hardware) and 96 637 868 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037383740 |
| SW upg. (SW màj., soft up, UpgSW) | 1037386162 |
Two numbers = this file: SW 1037383740 and SW upg. 1037386162. One number 1037386162 alone = another file, not this one. 1037383740 twice = the factory read.
Other files you may need
- Same hardware 0281012982: SW 1037386162 (PSA 9665091180) – Jumpy 1.6 HDi
- Other Citroën Jumpy EDC16C34 files: 0281013869 · 1037386177 upg. 1037393467
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281012982 1037383740 1037386162 a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën Jumpy 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037383740.
My tool shows SW 1037383740 and SW upg. 1037386162 – is this the file?
Yes, exactly this one: the flash holds the updated software 1037386162, and 1037383740 is the base number the ECU still reports.
My tool shows only “SW 1037386162” and nothing else. Same file?
No. A different file exists for 1037386162 alone – see that file. This page is for an ECU that shows both SW 1037383740 and SW upg. 1037386162.
Does it fit the Fiat Scudo 1.6 Multijet?
Yes – the Scudo is the twin of the Citroën Jumpy: same engine, same EDC16C34. Check 0 281 012 982 and 96 637 868 80 on the label and software 1037383740 in your tool before ordering.
Does it fit the Peugeot Expert 1.6 HDi?
Yes – the Expert is the twin of the Citroën Jumpy: same engine, same EDC16C34. Check 0 281 012 982 and 96 637 868 80 on the label and software 1037383740 in your tool before ordering.
Will this file work on a Fiat Scudo 1.6 D?
Only if the Scudo label reads HW 0281012982 / PSA 9663786880 and the tool shows 1037383740 / 1037386162. It is reported with this software but we did not read it from a Scudo ourselves.
