EDC15C2 0281011522 1037370785 ORI full BDM – Peugeot 807 2.2 HDi (PSA 9655816780)

20,00 €

  • Full BDM backup – not a flash-only OBD read
  • Flash 512 KB + EEPROM 95080 from the same ECU (1 KB)
  • Original, unmodified – SW 1037370785
  • Two independent reads of the same software, from two different ECUs
  • Instant download – 2 ZIPs (826 KB in total), each with an INFOS.html datasheet

Check before ordering: EDC15C2 0281011522 – label 0 281 011 522 · 96 558 167 80 – tool SW 1037370785, upgrade field empty or 1037370785.

Instant digital delivery — no shipping, no waiting

  • Every file manually verified before download
  • Pre-purchase support available — just ask
  • Secure card payment (Visa, Mastercard)
EDC15C2 0281011522 1037370785 ORI – Bosch ECU label, PSA 9655816780 – Peugeot 807 2.2 HDi
EDC15C2 0281011522 1037370785 ORI full BDM – Peugeot 807 2.2 HDi (PSA 9655816780)
20,00 €

Not sure this is your file? Send us a photo of your ECU label or a screenshot of your tool – we confirm the match before you order.

Contact us →

EDC15C2 0281011522 1037370785 ORI: the unmodified full BDM backup of a Bosch EDC15C2 fitted to the Peugeot 807 2.2 HDi (PSA 9655816780) – external flash 512 KB + EEPROM 95080 (1 KB) read on the bench.

What you get (2 ZIPs, 826 KB in total)

✔ EDC15C2 0281011522 1037370785 ORI full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work

Complete bench read of the Bosch EDC15C2 used in the Peugeot 807 2.2 HDi: external flash 512 KB + EEPROM 95080 (1 KB) from one and the same ECU, delivered as 2 ZIPs with an INFOS.html datasheet.

A true full BDM, not a flash-only OBD read. In addition, the download link is available right after payment.

Two independent reads of the same software, from two different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the other to compare or to double-check your own read – the differences are listed under Archive contents.

Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.

Compatible vehicles

VehicleEngineStatus
Citroën C82.2 HDitwin model – same vehicle as the Peugeot 807, Citroën badge
Fiat Ulysse2.2 JTDtwin model – same vehicle as the Peugeot 807, Fiat badge
Peugeot 8072.2 HDiconfirmed for this software
Lancia Phedra2.2 JTDtwin model – same vehicle as the Peugeot 807, Lancia badge
Citroën C52.2 HDireported, not confirmed

Hardware 0281011522 was fitted with 2 software states in our catalogue, so the engine badge is not enough: compare HW 0281011522 and PSA 9655816780 on the label, then the software number in your tool.

Same hardware 0281011522, different software 1037368845? That one is sold separately here.

Archive contents

Read #1 – 0281011522_9655816780_SW1037370785_N1.zip (406 KB)

FileMemorySize
0281011522_9655816780_SW1037370785_N1_FLASH.binExternal flash524 288 bytes (512 KB)
0281011522_9655816780_SW1037370785_N1_EEPROM_1KB.binEEPROM 950801 024 bytes (1 KB)
INFOS.htmlDatasheet: references, vehicles, file list, checksums (12 languages)–

Read #2 – 0281011522_9655816780_SW1037370785_N2.zip (421 KB)

FileMemorySize
0281011522_9655816780_SW1037370785_N2_FLASH.binExternal flash524 288 bytes (512 KB)
0281011522_9655816780_SW1037370785_N2_EEPROM_1KB.binEEPROM 950801 024 bytes (1 KB)
INFOS.htmlDatasheet: references, vehicles, file list, checksums (12 languages)–

Read #2 compared with read #1: 4 bytes differ in the flash (2 areas: 0x07EC12–0x07EC13, 0x07EC3A–0x07EC3B); 193 bytes differ in the EEPROM (29 areas: 0x000008–0x000009, 0x00000B–0x00000C, 0x00000F, …).

Both memories were read from the same box, so they match each other (including the donor’s immobiliser data). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.

EDC15C2 0281011522 1037370785 ORI – references

ECUBosch EDC15C2
Bosch hardware (HW)0281011522 – printed 0 281 011 522 on the label
PSA part number9655816780 – printed 96 558 167 80
Software (SW)1037370785 – also written SW1037370785
Upgrade / SW upg.none – your tool shows 1037370785 in both fields, or leaves the second one empty
Memory suppliedExternal flash 512 KB + EEPROM 95080 (1 KB)
Read methodBench / BDM, complete read, file unmodified
DeliveryZIPs 826 KB, instant download after payment

Tuners and forums call it a full backup, full BDM or original file; French-speaking customers say fichier d’origine, Italians file ori.

Notes on this file

We read two EDC15C2 ECUs running software 1037370785 for this page. Hardware 0281011522 is known with 2 software versions in our catalogue; this page is 1037370785.

Readable and writable with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. Still, very occasionally the file needs aligning in a hex editor or WinOLS for your setup. For professional use – workshops and ECU technicians.

How to identify your ECU

On the label

On the Bosch label of the EDC15C2 you will read 0 281 011 522 (hardware) and 96 558 167 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.

EDC15C2 0281011522 1037370785 ORI – Bosch ECU label, PSA 9655816780 – Peugeot 807 2.2 HDi

What KESS / KTAG show

FieldWhat the tool shows
HWoften empty – use the label
SW1037370785
SW upg. (SW màj., soft up, UpgSW)empty, or 1037370785 again

Your tool should show 1037370785 as SW and either nothing or 1037370785 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.

Other files you may need

Your tool shows another number? Ask for it – we read new references every week.

Questions about this file

Is EDC15C2 0281011522 1037370785 ORI a full BDM backup or only the flash?

Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Peugeot 807 2.2 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037370785.

My tool shows SW 1037370785 but the HW field is empty. Right file?

Yes, KESS and KTAG often leave HW blank. Check 0 281 011 522 and 96 558 167 80 on the label; if the upgrade line is empty or repeats 1037370785, this is your file.

Does it fit the Citroën C8 2.2 HDi?

Yes – the C8 is the twin of the Peugeot 807: same engine, same EDC15C2. Check 0 281 011 522 and 96 558 167 80 on the label and software 1037370785 in your tool before ordering.

Does it fit the Fiat Ulysse 2.2 JTD?

Yes – the Ulysse is the twin of the Peugeot 807: same engine, same EDC15C2. Check 0 281 011 522 and 96 558 167 80 on the label and software 1037370785 in your tool before ordering.

Will this file work on a Citroën C5 2.2 HDi?

Only if the C5 label reads HW 0281011522 / PSA 9655816780 and the tool shows 1037370785. It is reported with this software but we did not read it from a C5 ourselves.

Same hardware 0281011522 but my tool shows SW 1037368845?

Then you need the other file for this hardware: SW 1037368845 with PSA 9650932080, sold on its own page. 0281011522 alone is not enough to choose.

Why are there 2 downloads for one software?

We read 2 ECUs running 1037370785. Write read #1; the other differ by VIN, immobiliser and adaptation data in the EEPROM, useful to compare with your own read.

Does the EEPROM contain the immobiliser of the donor 807?

Yes, as read. This is the original state of ECU 0281011522, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
