EDC16C34 0281011561 1037371808 ORI: the unmodified full BDM backup of a Bosch EDC16C34 fitted to the Citroën C5 1.6 HDi (PSA 9656974780) – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) read on the bench.
What you get (ZIP, 633 KB)
✔ EDC16C34 0281011561 1037371808 ORI full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (633 KB) holding the software of a Bosch EDC16C34 read on the bench (Citroën C5 1.6 HDi application): external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from the same unit, with an INFOS.html datasheet.
In forum terms: a full BDM / full backup, flash and EEPROM together, not an OBD flash read. Also, the download opens as soon as the payment is confirmed.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Power | Status |
|---|---|---|---|
| Citroën C5 | 1.6 HDi | 109 hp / 80 kW | confirmed for this software |
Do not rely on the model alone: check HW 0281011561 and PSA 9656974780 on the label, then 1037371808 on the identification screen of your tool.
Archive contents
| File | Memory | Size |
|---|---|---|
0281011561_9656974780_SW1037371808_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011561_9656974780_SW1037371808_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011561_9656974780_SW1037371808_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011561_9656974780_SW1037371808_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
One EEPROM, three file formats (2 KB / 4 KB / 8 KB) so that every tool finds the size it expects – 2 KB is the chip itself, the content is identical.
Because flash and EEPROM come from one ECU, writing both restores a coherent unit (donor immobiliser data included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC16C34 with the usual tools.
EDC16C34 0281011561 1037371808 ORI – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281011561 – printed 0 281 011 561 on the label |
| PSA part number | 9656974780 – printed 96 569 747 80 |
| Software (SW) | 1037371808 – also written SW1037371808 |
| Upgrade / SW upg. | none – your tool shows 1037371808 in both fields, or leaves the second one empty |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 633 KB, instant download after payment |
Professionals call this kind of file a full BDM backup or an ORI file – in French fichier d’origine, in Italian file ori.
Notes on this file
Engine: Citroën C5 1.6 HDi (109 hp).
Works with all common tools – KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases an alignment with a hex editor or WinOLS may be needed before writing. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC16C34 you will read 0 281 011 561 (hardware) and 96 569 747 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037371808 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037371808 again |
Expected ID screen: SW 1037371808, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Same software 1037371808: upgrade 1037380723
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281011561 1037371808 ORI a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën C5 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037371808.
My tool shows SW 1037371808 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 561 and 96 569 747 80 on the label; if the upgrade line is empty or repeats 1037371808, this is your file.
Does the EEPROM contain the immobiliser of the donor C5?
Yes, as read. This is the original state of ECU 0281011561, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
Which EEPROM file should I write – 2 / 4 / 8 KB?
The size your tool proposes for a 95160: 2 KB is the native format, the others hold the same data in the larger formats some tools expect. Most tools simply refuse a wrong size.
