EDC15C2 0281011334 1037368584 ORI – original full BDM backup from a Bosch EDC15C2 fitted to the Citroën C8 2.0 HDi (PSA 9652590480): external flash 512 KB + EEPROM 95080 (1 KB), bench read, nothing modified.
What you get (ZIP, 411 KB)
✔ EDC15C2 0281011334 1037368584 ORI full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (411 KB) with the complete memory of a Bosch EDC15C2, read on the bench (Citroën C8 2.0 HDi application): external flash 512 KB + EEPROM 95080 (1 KB), taken from the same ECU, plus an INFOS.html datasheet.
In forum terms: a full BDM / full backup, flash and EEPROM together, not an OBD flash read. In addition, the download link is available right after payment.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Status |
|---|---|---|
| Fiat Ulysse | 2.0 JTD | twin model – same vehicle as the Citroën C8, Fiat badge |
| Citroën C8 | 2.0 HDi | confirmed for this software |
| Peugeot 807 | 2.0 HDi | twin model – same vehicle as the Citroën C8, Peugeot badge |
| Lancia Phedra | 2.0 JTD | twin model – same vehicle as the Citroën C8, Lancia badge |
Do not rely on the model alone: check HW 0281011334 and PSA 9652590480 on the label, then 1037368584 on the identification screen of your tool.
Archive contents
| File | Memory | Size |
|---|---|---|
0281011334_9652590480_SW1037368584_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281011334_9652590480_SW1037368584_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Because flash and EEPROM come from one ECU, writing both restores a coherent unit (donor immobiliser data included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.
EDC15C2 0281011334 1037368584 ORI – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281011334 – printed 0 281 011 334 on the label |
| PSA part number | 9652590480 – printed 96 525 904 80 |
| Software (SW) | 1037368584 – also written SW1037368584 |
| Upgrade / SW upg. | none – your tool shows 1037368584 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 411 KB, instant download after payment |
Professionals call this kind of file a full BDM backup or an ORI file – in French fichier d’origine, in Italian file ori.
Notes on this file
This page covers one exact software: EDC15C2 0281011334 with SW 1037368584. Another number on your tool means another file – use the search or ask us.
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC15C2. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC15C2 you will read 0 281 011 334 (hardware) and 96 525 904 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037368584 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037368584 again |
Expected ID screen: SW 1037368584, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281011334 1037368584 ORI a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Citroën C8 2.0 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037368584.
My tool shows SW 1037368584 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 334 and 96 525 904 80 on the label; if the upgrade line is empty or repeats 1037368584, this is your file.
Does it fit the Fiat Ulysse 2.0 JTD?
Yes – the Ulysse is the twin of the Citroën C8: same engine, same EDC15C2. Check 0 281 011 334 and 96 525 904 80 on the label and software 1037368584 in your tool before ordering.
Does it fit the Peugeot 807 2.0 HDi?
Yes – the 807 is the twin of the Citroën C8: same engine, same EDC15C2. Check 0 281 011 334 and 96 525 904 80 on the label and software 1037368584 in your tool before ordering.
Will this file work on a Peugeot 406?
Only if the 406 label reads HW 0281011334 / PSA 9652590480 and the tool shows 1037368584. It is reported with this software but we did not read it from a 406 ourselves.
Does the EEPROM contain the immobiliser of the donor C8?
Yes, as read. This is the original state of ECU 0281011334, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
