EDC15C2 0281010880 1037364125 ORI is the original full BDM backup of a Bosch EDC15C2 fitted to the Peugeot 607 2.2 HDi (PSA 9648268180): external flash 512 KB + EEPROM 95080 (1 KB), read on the bench and delivered unmodified.
What you get (ZIP, 401 KB)
✔ EDC15C2 0281010880 1037364125 ORI full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (401 KB) with the complete memory of a Bosch EDC15C2, read on the bench (Peugeot 607 2.2 HDi application): external flash 512 KB + EEPROM 95080 (1 KB), taken from the same ECU, plus an INFOS.html datasheet.
This is what tuners call a full BDM or full backup – not the flash alone. In addition, the download link is available right after payment.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Status |
|---|---|---|
| Peugeot 607 | 2.2 HDi | confirmed for this software |
Two 607 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281010880, PSA 9648268180 – and the software 1037364125 shown by your tool before ordering.
Archive contents
| File | Memory | Size |
|---|---|---|
0281010880_9648268180_SW1037364125_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010880_9648268180_SW1037364125_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Because flash and EEPROM come from one ECU, writing both restores a coherent unit (donor immobiliser data included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.
EDC15C2 0281010880 1037364125 ORI – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281010880 – printed 0 281 010 880 on the label |
| PSA part number | 9648268180 – printed 96 482 681 80 |
| Software (SW) | 1037364125 – also written SW1037364125 |
| Upgrade / SW upg. | none – your tool shows 1037364125 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 401 KB, instant download after payment |
In workshop language this is an ORI file or full BDM backup of the EDC15C2 (fichier d’origine in French, file ori in Italian).
Notes on this file
This page covers one exact software: EDC15C2 0281010880 with SW 1037364125. Another number on your tool means another file – use the search or ask us.
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC15C2. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 010 880 and 96 482 681 80. The 1039S… sticker is not a software number – 1037364125 is only visible through a tool or in INFOS.html.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037364125 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037364125 again |
Expected ID screen: SW 1037364125, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281010880 1037364125 ORI a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Peugeot 607 2.2 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037364125.
My tool shows SW 1037364125 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 010 880 and 96 482 681 80 on the label; if the upgrade line is empty or repeats 1037364125, this is your file.
Does the EEPROM contain the immobiliser of the donor 607?
Yes, as read. This is the original state of ECU 0281010880, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
