EDC15C2 0281010248 1037359169 ORI is the original full BDM backup of a Bosch EDC15C2 fitted to the Peugeot 406 2.0 HDi (PSA 9635157080): external flash 512 KB + EEPROM 95080 (1 KB), read on the bench and delivered unmodified.
What you get (6 ZIPs, 2.2 MB in total)
✔ EDC15C2 0281010248 1037359169 ORI full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC15C2 used in the Peugeot 406 2.0 HDi: external flash 512 KB + EEPROM 95080 (1 KB) from one and the same ECU, delivered as 6 ZIPs with an INFOS.html datasheet.
This is what tuners call a full BDM or full backup – not the flash alone. In addition, the download link is available right after payment.
6 independent reads of the same software, from 6 different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the others to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Peugeot 406 | 2.0 HDi | RHY | 90 hp / 66 kW | confirmed for this software |
Two 406 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281010248, PSA 9635157080 – and the software 1037359169 shown by your tool before ordering.
Same hardware 0281010248, different software 1037353494? That one is sold separately here.
Archive contents
Read #1 – 0281010248_9635157080_SW1037359169_N1.zip (361 KB)
| File | Memory | Size |
|---|---|---|
0281010248_9635157080_SW1037359169_N1_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010248_9635157080_SW1037359169_N1_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 – 0281010248_9635157080_SW1037359169_N2.zip (376 KB)
| File | Memory | Size |
|---|---|---|
0281010248_9635157080_SW1037359169_N2_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010248_9635157080_SW1037359169_N2_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #3 – 0281010248_9635157080_SW1037359169_N3.zip (376 KB)
| File | Memory | Size |
|---|---|---|
0281010248_9635157080_SW1037359169_N3_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010248_9635157080_SW1037359169_N3_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #4 – 0281010248_9635157080_SW1037359169_N4.zip (376 KB)
| File | Memory | Size |
|---|---|---|
0281010248_9635157080_SW1037359169_N4_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010248_9635157080_SW1037359169_N4_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #5 – 0281010248_9635157080_SW1037359169_N5.zip (376 KB)
| File | Memory | Size |
|---|---|---|
0281010248_9635157080_SW1037359169_N5_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010248_9635157080_SW1037359169_N5_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #6 – 0281010248_9635157080_SW1037359169_N6.zip (376 KB)
| File | Memory | Size |
|---|---|---|
0281010248_9635157080_SW1037359169_N6_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010248_9635157080_SW1037359169_N6_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 compared with read #1: the flash is identical; 90 bytes differ in the EEPROM (29 areas: 0x00003F, 0x000041, 0x000058, …).
Read #3 compared with read #1: 5 bytes differ in the flash (2 areas: 0x07EC12–0x07EC14, 0x07EC3A–0x07EC3B); 240 bytes differ in the EEPROM (21 areas: 0x000007–0x000009, 0x00000B–0x00000C, 0x00000F, …).
Read #4 compared with read #1: 5 bytes differ in the flash (2 areas: 0x07EC12–0x07EC14, 0x07EC3A–0x07EC3B); 251 bytes differ in the EEPROM (27 areas: 0x000007–0x000009, 0x00000B–0x00000C, 0x00000F, …).
Read #5 compared with read #1: 3 bytes differ in the flash (2 areas: 0x07EC12, 0x07EC3A–0x07EC3B); 227 bytes differ in the EEPROM (23 areas: 0x00000C, 0x00000F, 0x000017, …).
Read #6 compared with read #1: 5 bytes differ in the flash (2 areas: 0x07EC12–0x07EC14, 0x07EC3A–0x07EC3B); 221 bytes differ in the EEPROM (32 areas: 0x000007–0x000008, 0x00000B–0x00000C, 0x00000F, …).
Because flash and EEPROM come from one ECU, writing both restores a coherent unit (donor immobiliser data included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.
EDC15C2 0281010248 1037359169 ORI – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281010248 – printed 0 281 010 248 on the label |
| PSA part number | 9635157080 – printed 96 351 570 80 |
| Software (SW) | 1037359169 – also written SW1037359169 |
| Upgrade / SW upg. | none – your tool shows 1037359169 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 2.2 MB, instant download after payment |
Tuners and forums call it a full backup, full BDM or original file; French-speaking customers say fichier d’origine, Italians file ori.
Notes on this file
We read 6 EDC15C2 ECUs running software 1037359169 for this page. Hardware 0281010248 is known with 2 software versions in our catalogue; this page is 1037359169. Engine: Peugeot 406 2.0 HDi (90 hp, engine code RHY).
Works with all common tools – KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases an alignment with a hex editor or WinOLS may be needed before writing. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC15C2 housing shows the hardware number 0 281 010 248 and the PSA number 96 351 570 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037359169 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037359169 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037359169 again |
Expected ID screen: SW 1037359169, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Same hardware 0281010248: SW 1037353494 (PSA 9635157080) – 406 2.0 HDi
- Other Peugeot 406 EDC15C2 files: 0281010361 · 1037353047 · 0281010363 · 1037353049 · 0281010370 · 1037353306 · 0281010590 · 1037353360 · 0281010627 · 1037353401
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281010248 1037359169 ORI a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Peugeot 406 2.0 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037359169.
My tool shows SW 1037359169 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 010 248 and 96 351 570 80 on the label; if the upgrade line is empty or repeats 1037359169, this is your file.
Same hardware 0281010248 but my tool shows SW 1037353494?
Then you need the other file for this hardware: SW 1037353494 with PSA 9635157080, sold on its own page. 0281010248 alone is not enough to choose.
Why are there 6 downloads for one software?
We read 6 ECUs running 1037359169. Write read #1; the others differ by VIN, immobiliser and adaptation data in the EEPROM, useful to compare with your own read.
Does the EEPROM contain the immobiliser of the donor 406?
Yes, as read. This is the original state of ECU 0281010248, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
