EDC16C3 0281011558 1037371807 ORI – original full BDM backup from a Bosch EDC16C3 fitted to the Peugeot 407 1.6 HDi (PSA 9656974680): external flash 1 MB + EEPROM 95160 (2 / 4 KB formats, multi-tool) + Internal flash MPC 448 KB, bench read, nothing modified.
What you get (ZIP, 623 KB)
✔ EDC16C3 0281011558 1037371807 ORI full BDM backup – external flash 1 MB + EEPROM 95160 (2 / 4 KB formats, multi-tool) + Internal flash MPC 448 KB, read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (623 KB) with the complete memory of a Bosch EDC16C3, read on the bench (Peugeot 407 1.6 HDi application): external flash 1 MB + EEPROM 95160 (2 / 4 KB formats, multi-tool) + Internal flash MPC 448 KB, taken from the same ECU, plus an INFOS.html datasheet.
In forum terms: a full BDM / full backup, flash and EEPROM together, not an OBD flash read. Also, the download opens as soon as the payment is confirmed.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Status |
|---|---|---|
| Peugeot 407 | 1.6 HDi | confirmed for this software |
| Peugeot 407 | 2.0 HDi | reported, not confirmed |
Do not rely on the model alone: check HW 0281011558 and PSA 9656974680 on the label, then 1037371807 on the identification screen of your tool.
Same hardware 0281011558, different software 1037370763? That one is sold separately here.
Archive contents
| File | Memory | Size |
|---|---|---|
0281011558_9656974680_SW1037371807_FLASH.bin | External flash | 1 048 576 bytes (1 MB) |
0281011558_9656974680_SW1037371807_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011558_9656974680_SW1037371807_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011558_9656974680_SW1037371807_MPC.bin | Internal flash (MPC) | 459 008 bytes (448 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
One EEPROM, two file formats (2 KB / 4 KB) so that every tool finds the size it expects – 2 KB is the chip itself, the content is identical.
Flash and EEPROM are from the same unit, so writing both gives a coherent ECU (immobiliser data of the donor car included). The MPC internal flash is included as well (448 KB).
EDC16C3 0281011558 1037371807 ORI – references
| ECU | Bosch EDC16C3 |
| Bosch hardware (HW) | 0281011558 – printed 0 281 011 558 on the label |
| PSA part number | 9656974680 – printed 96 569 746 80 |
| Software (SW) | 1037371807 – also written SW1037371807 |
| Upgrade / SW upg. | none – your tool shows 1037371807 in both fields, or leaves the second one empty |
| Memory supplied | External flash 1 MB + EEPROM 95160 (2 / 4 KB formats, multi-tool) + Internal flash MPC 448 KB |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 623 KB, instant download after payment |
Professionals call this kind of file a full BDM backup or an ORI file – in French fichier d’origine, in Italian file ori.
Notes on this file
Hardware 0281011558 is known with 2 software versions in our catalogue; this page is 1037371807.
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC16C3. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC16C3 housing shows the hardware number 0 281 011 558 and the PSA number 96 569 746 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037371807 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037371807 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037371807 again |
Your tool should show 1037371807 as SW and either nothing or 1037371807 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Same hardware 0281011558: SW 1037370763 (PSA 9689230080) – 307 1.6 HDi
- Bosch EDC16C3 family: all EDC16C3 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C3 0281011558 1037371807 ORI a full BDM backup or only the flash?
Full backup: the 1 MB external flash and the 95160 EEPROM were read together from the same ECU (Peugeot 407 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037371807.
My tool shows SW 1037371807 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 558 and 96 569 746 80 on the label; if the upgrade line is empty or repeats 1037371807, this is your file.
Will this file work on a Citroën C4?
Only if the C4 label reads HW 0281011558 / PSA 9656974680 and the tool shows 1037371807. It is reported with this software but we did not read it from a C4 ourselves.
Same hardware 0281011558 but my tool shows SW 1037370763?
Then you need the other file for this hardware: SW 1037370763 with PSA 9689230080, sold on its own page. 0281011558 alone is not enough to choose.
Does the EEPROM contain the immobiliser of the donor 407?
Yes, as read. This is the original state of ECU 0281011558, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
Which EEPROM file should I write – 2 / 4 KB?
The size your tool proposes for a 95160: 2 KB is the native format, the others hold the same data in the larger formats some tools expect. Most tools simply refuse a wrong size.
