EDC16C34 0281011802 1037371537: the unmodified full BDM backup of a Bosch EDC16C34 fitted to the Citroën Xsara Picasso 1.6 HDi (PSA 9656841180) – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) read on the bench.
What you get (2 ZIPs, 1.3 MB in total)
✔ EDC16C34 0281011802 1037371537 full BDM backup – external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC16C34 used in the Citroën Xsara Picasso 1.6 HDi: external flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) from one and the same ECU, delivered as 2 ZIPs with an INFOS.html datasheet.
This is what tuners call a full BDM or full backup – not the flash alone. In addition, the download link is available right after payment.
Two independent reads of the same software, from two different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the other to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Citroën Xsara Picasso | 1.6 HDi | 9HX | 110 hp / 80 kW | confirmed for this software |
| Citroën Xsara | 1.6 HDi | — | 110 hp / 80 kW | reported, not confirmed |
Hardware 0281011802 was fitted with 2 software states in our catalogue, so the engine badge is not enough: compare HW 0281011802 and PSA 9656841180 on the label, then the software number in your tool.
With HW 0281011802 but PSA 9656841080 / SW 1037372086, take that file.
Archive contents
Read #1 – 0281011802_9656841180_SW1037371537_N1.zip (638 KB)
| File | Memory | Size |
|---|---|---|
0281011802_9656841180_SW1037371537_N1_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011802_9656841180_SW1037371537_N1_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011802_9656841180_SW1037371537_N1_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011802_9656841180_SW1037371537_N1_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 – 0281011802_9656841180_SW1037371537_N2.zip (654 KB)
| File | Memory | Size |
|---|---|---|
0281011802_9656841180_SW1037371537_N2_FLASH.bin | External flash | 2 097 152 bytes (2 MB) |
0281011802_9656841180_SW1037371537_N2_EEPROM_2KB.bin | EEPROM 95160, native format | 2 048 bytes (2 KB) |
0281011802_9656841180_SW1037371537_N2_EEPROM_4KB.bin | EEPROM 95160, 4 KB format, same data | 4 096 bytes (4 KB) |
0281011802_9656841180_SW1037371537_N2_EEPROM_8KB.bin | EEPROM 95160, 8 KB format, same data | 8 192 bytes (8 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 compared with read #1: 5 bytes differ in the flash (2 areas: 0x007FC4–0x007FC5, 0x007FC9–0x007FCB); 472 bytes differ in the EEPROM (102 areas: 0x000001–0x000003, 0x00001E–0x00001F, 0x000023–0x000025, …).
Multi-tool ready: the EEPROM comes in three formats (2 KB / 4 KB / 8 KB), same content. 2 KB is native; pick the size your tool asks for.
Because flash and EEPROM come from one ECU, writing both restores a coherent unit (donor immobiliser data included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC16C34 with the usual tools.
EDC16C34 0281011802 1037371537 – references
| ECU | Bosch EDC16C34 |
| Bosch hardware (HW) | 0281011802 – printed 0 281 011 802 on the label |
| PSA part number | 9656841180 – printed 96 568 411 80 |
| Software (SW) | 1037371537 – also written SW1037371537 |
| Upgrade / SW upg. | none – your tool shows 1037371537 in both fields, or leaves the second one empty |
| Memory supplied | External flash 2 MB + EEPROM 95160 (2 / 4 / 8 KB formats, multi-tool) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 1.3 MB, instant download after payment |
In workshop language this is an ORI file or full BDM backup of the EDC16C34 (fichier d’origine in French, file ori in Italian).
Notes on this file
We read two EDC16C34 ECUs running software 1037371537 for this page. Hardware 0281011802 is known with 2 software versions in our catalogue; this page is 1037371537. Engine: Citroën Xsara Picasso 1.6 HDi (110 hp, engine code 9HX).
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC16C34. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 011 802 and 96 568 411 80. The 1039S… sticker is not a software number – 1037371537 is only visible through a tool or in INFOS.html.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037371537 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037371537 again |
Your tool should show 1037371537 as SW and either nothing or 1037371537 again as SW upg. (SW màj. / soft up / UpgSW). A different number on that second line means an updated ECU: look for the file with that upgrade number.
Other files you may need
- Same hardware 0281011802: SW 1037372086 (PSA 9656841080) – Xsara 1.6 HDi · SW 1037372086 (PSA 9656841080) – Xsara 1.6 HDi
- Other Citroën Xsara Picasso EDC16C34 files: 0281011392 · 1037374943 upg. 1037380091 · 0281012468 · 1037374952 · 0281012466 · 1037375962 · 0281012466 · 1037377720 · 0281012468 · 1037380739
- Bosch EDC16C34 family: all EDC16C34 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC16C34 0281011802 1037371537 a full BDM backup or only the flash?
Full backup: the 2 MB external flash and the 95160 EEPROM were read together from the same ECU (Citroën Xsara Picasso 1.6 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037371537.
My tool shows SW 1037371537 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 802 and 96 568 411 80 on the label; if the upgrade line is empty or repeats 1037371537, this is your file.
Will this file work on a Citroën Xsara 1.6 HDi?
Only if the Xsara label reads HW 0281011802 / PSA 9656841180 and the tool shows 1037371537. It is reported with this software but we did not read it from a Xsara ourselves.
Same hardware 0281011802 but my tool shows SW 1037372086?
Then you need the other file for this hardware: SW 1037372086 with PSA 9656841080, sold on its own page. 0281011802 alone is not enough to choose.
Why are there 2 downloads for one software?
We read 2 ECUs running 1037371537. Write read #1; the other differ by VIN, immobiliser and adaptation data in the EEPROM, useful to compare with your own read.
Does the EEPROM contain the immobiliser of the donor Xsara Picasso?
Yes, as read. This is the original state of ECU 0281011802, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
