EDC15C2 0281011521 1037371515 – original full BDM backup from a Bosch EDC15C2 fitted to the Citroën Xsara Picasso 2.0 HDi (PSA 9656314380): external flash 512 KB + EEPROM 95080 (1 KB), bench read, nothing modified.
What you get (ZIP, 413 KB)
✔ EDC15C2 0281011521 1037371515 full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (413 KB) with the complete memory of a Bosch EDC15C2, read on the bench (Citroën Xsara Picasso 2.0 HDi application): external flash 512 KB + EEPROM 95080 (1 KB), taken from the same ECU, plus an INFOS.html datasheet.
In forum terms: a full BDM / full backup, flash and EEPROM together, not an OBD flash read. Moreover, the ZIP is delivered instantly once the order is paid.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Citroën Xsara Picasso | 2.0 HDi | RHY | 90 hp / 66 kW | confirmed for this software |
Two Xsara Picasso with the same engine can carry different software, so match the numbers on the ECU label – HW 0281011521, PSA 9656314380 – and the software 1037371515 shown by your tool before ordering.
Same hardware 0281011521, different software 1037369504? That one is sold separately here.
Archive contents
| File | Memory | Size |
|---|---|---|
0281011521_9656314380_SW1037371515_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281011521_9656314380_SW1037371515_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Both memories were read from the same box, so they match each other (including the donor’s immobiliser data). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.
EDC15C2 0281011521 1037371515 – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281011521 – printed 0 281 011 521 on the label |
| PSA part number | 9656314380 – printed 96 563 143 80 |
| Software (SW) | 1037371515 – also written SW1037371515 |
| Upgrade / SW upg. | none – your tool shows 1037371515 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 413 KB, instant download after payment |
Professionals call this kind of file a full BDM backup or an ORI file – in French fichier d’origine, in Italian file ori.
Notes on this file
Hardware 0281011521 is known with 3 software versions in our catalogue; this page is 1037371515. Engine: Citroën Xsara Picasso 2.0 HDi (90 hp, engine code RHY).
Works with all common tools – KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases an alignment with a hex editor or WinOLS may be needed before writing. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC15C2 you will read 0 281 011 521 (hardware) and 96 563 143 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037371515 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037371515 again |
Expected ID screen: SW 1037371515, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Same hardware 0281011521: SW 1037369504 (PSA 9651593480) – Xsara Picasso 2.0 HDi · SW 1037371028 (PSA 9654693280) – Xsara Picasso 2.0 HDi
- Other Citroën Xsara Picasso EDC15C2 files: 0281010358 · 1037353044 · 0281010595 · 1037353363 · 0281010358 · 1037353377 · 0281010750 · 1037353528 · 0281010962 · 1037353913
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281011521 1037371515 a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Citroën Xsara Picasso 2.0 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037371515.
My tool shows SW 1037371515 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 011 521 and 96 563 143 80 on the label; if the upgrade line is empty or repeats 1037371515, this is your file.
Will this file work on a Citroën Xsara?
Only if the Xsara label reads HW 0281011521 / PSA 9656314380 and the tool shows 1037371515. It is reported with this software but we did not read it from a Xsara ourselves.
Same hardware 0281011521 but my tool shows SW 1037369504?
Then you need the other file for this hardware: SW 1037369504 with PSA 9651593480, sold on its own page. 0281011521 alone is not enough to choose.
Does the EEPROM contain the immobiliser of the donor Xsara Picasso?
Yes, as read. This is the original state of ECU 0281011521, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
