EDC15C2 0281010137 1037359162 – original full BDM backup from a Bosch EDC15C2 fitted to the Citroën Xsara Picasso 2.0 HDi (PSA 9635158480): external flash 512 KB + EEPROM 95080 (1 KB), bench read, nothing modified.
What you get (2 ZIPs, 742 KB in total)
✔ EDC15C2 0281010137 1037359162 full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Each ZIP archive with the complete memory of a Bosch EDC15C2, read on the bench (Citroën Xsara Picasso 2.0 HDi application): external flash 512 KB + EEPROM 95080 (1 KB), taken from the same ECU, plus an INFOS.html datasheet.
A true full BDM, not a flash-only OBD read. In addition, the download link is available right after payment.
Two independent reads of the same software, from two different ECUs. Each read is complete and unmodified. Read #1 is the one to write; keep the other to compare or to double-check your own read – the differences are listed under Archive contents.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Years | Status |
|---|---|---|---|---|---|
| Citroën Xsara Picasso | 2.0 HDi | RHY | 90 hp / 66 kW | 1999-2011 | confirmed for this software |
Two Xsara Picasso with the same engine can carry different software, so match the numbers on the ECU label – HW 0281010137, PSA 9635158480 – and the software 1037359162 shown by your tool before ordering.
Archive contents
Read #1 – 0281010137_9635158480_SW1037359162_N1.zip (363 KB)
| File | Memory | Size |
|---|---|---|
0281010137_9635158480_SW1037359162_N1_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010137_9635158480_SW1037359162_N1_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 – 0281010137_9635158480_SW1037359162_N2.zip (378 KB)
| File | Memory | Size |
|---|---|---|
0281010137_9635158480_SW1037359162_N2_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010137_9635158480_SW1037359162_N2_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Read #2 compared with read #1: 4 bytes differ in the flash (2 areas: 0x07EC12–0x07EC13, 0x07EC3A–0x07EC3B); 263 bytes differ in the EEPROM (32 areas: 0x000009, 0x00000B–0x00000C, 0x00000F, …).
Flash and EEPROM are from the same unit, so writing both gives a coherent ECU (immobiliser data of the donor car included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.
EDC15C2 0281010137 1037359162 – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281010137 – printed 0 281 010 137 on the label |
| PSA part number | 9635158480 – printed 96 351 584 80 |
| Software (SW) | 1037359162 – also written SW1037359162 |
| Upgrade / SW upg. | none – your tool shows 1037359162 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIPs 742 KB, instant download after payment |
In workshop language this is an ORI file or full BDM backup of the EDC15C2 (fichier d’origine in French, file ori in Italian).
Notes on this file
We read two EDC15C2 ECUs running software 1037359162 for this page. Engine: Citroën Xsara Picasso 2.0 HDi (90 hp, engine code RHY, 1999-2011).
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC15C2. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
Two numbers on the label matter: 0 281 010 137 and 96 351 584 80. The 1039S… sticker is not a software number – 1037359162 is only visible through a tool or in INFOS.html.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037359162 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037359162 again |
Expected ID screen: SW 1037359162, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281010137 1037359162 a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Citroën Xsara Picasso 2.0 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037359162.
My tool shows SW 1037359162 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 010 137 and 96 351 584 80 on the label; if the upgrade line is empty or repeats 1037359162, this is your file.
Why are there 2 downloads for one software?
We read 2 ECUs running 1037359162. Write read #1; the other differ by VIN, immobiliser and adaptation data in the EEPROM, useful to compare with your own read.
Does the EEPROM contain the immobiliser of the donor Xsara Picasso?
Yes, as read. This is the original state of ECU 0281010137, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
