EDC15C2 0281010138 1037359141 ORI: the unmodified full BDM backup of a Bosch EDC15C2 fitted to the Citroën Berlingo 2.0 HDi (PSA 9636255480) – external flash 512 KB + EEPROM 95080 (1 KB) read on the bench.
What you get (ZIP, 363 KB)
✔ EDC15C2 0281010138 1037359141 ORI full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
One ZIP archive (363 KB) holding the software of a Bosch EDC15C2 read on the bench (Citroën Berlingo 2.0 HDi application): external flash 512 KB + EEPROM 95080 (1 KB) from the same unit, with an INFOS.html datasheet.
In forum terms: a full BDM / full backup, flash and EEPROM together, not an OBD flash read. Also, the download opens as soon as the payment is confirmed.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Engine code | Power | Status |
|---|---|---|---|---|
| Peugeot Partner | 2.0 HDi | RHY | 90 hp / 66 kW | twin model – same vehicle as the Citroën Berlingo, Peugeot badge |
| Citroën Berlingo | 2.0 HDi | RHY | 90 hp / 66 kW | confirmed for this software |
Two Berlingo with the same engine can carry different software, so match the numbers on the ECU label – HW 0281010138, PSA 9636255480 – and the software 1037359141 shown by your tool before ordering.
Archive contents
| File | Memory | Size |
|---|---|---|
0281010138_9636255480_SW1037359141_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010138_9636255480_SW1037359141_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Because flash and EEPROM come from one ECU, writing both restores a coherent unit (donor immobiliser data included). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.
EDC15C2 0281010138 1037359141 ORI – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281010138 – printed 0 281 010 138 on the label |
| PSA part number | 9636255480 – printed 96 362 554 80 |
| Software (SW) | 1037359141 – also written SW1037359141 |
| Upgrade / SW upg. | none – your tool shows 1037359141 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 363 KB, instant download after payment |
Tuners and forums call it a full backup, full BDM or original file; French-speaking customers say fichier d’origine, Italians file ori.
Notes on this file
Engine: Citroën Berlingo 2.0 HDi (90 hp, engine code RHY).
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC15C2. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
On the Bosch label of the EDC15C2 you will read 0 281 010 138 (hardware) and 96 362 554 80 (PSA), often with a Bosch sticker number beginning 1039S. The sticker number is a production reference, not the software: only a tool read, or the INFOS.html in this archive, gives the 1037… numbers.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037359141 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037359141 again |
Expected ID screen: SW 1037359141, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281010138 1037359141 ORI a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Citroën Berlingo 2.0 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037359141.
My tool shows SW 1037359141 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 010 138 and 96 362 554 80 on the label; if the upgrade line is empty or repeats 1037359141, this is your file.
Does it fit the Peugeot Partner 2.0 HDi?
Yes – the Partner is the twin of the Citroën Berlingo: same engine, same EDC15C2. Check 0 281 010 138 and 96 362 554 80 on the label and software 1037359141 in your tool before ordering.
Does the EEPROM contain the immobiliser of the donor Berlingo?
Yes, as read. This is the original state of ECU 0281010138, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
