EDC15C2 0281010877 1037353776 ORI is the original full BDM backup of a Bosch EDC15C2 fitted to the Peugeot 406 2.2 HDi (PSA 9645532880): external flash 512 KB + EEPROM 95080 (1 KB), read on the bench and delivered unmodified.
What you get (ZIP, 400 KB)
✔ EDC15C2 0281010877 1037353776 ORI full BDM backup – external flash 512 KB + EEPROM 95080 (1 KB), read from the same ECU
✔ INFOS.html datasheet in 12 languages
✔ Unmodified original read – no tuning, no immobilizer change, no checksum work
Complete bench read of the Bosch EDC15C2 used in the Peugeot 406 2.2 HDi: external flash 512 KB + EEPROM 95080 (1 KB) from one and the same ECU, delivered as a ZIP with an INFOS.html datasheet.
This is what tuners call a full BDM or full backup – not the flash alone. Moreover, the ZIP is delivered instantly once the order is paid.
Not sure it is your file? For example, send us a photo of the ECU label or a screenshot of your tool’s identification screen before ordering – we confirm the match.
Compatible vehicles
| Vehicle | Engine | Years | Status |
|---|---|---|---|
| Peugeot 406 | 2.2 HDi | 1995-2005 | confirmed for this software |
| Peugeot 206 | 2.0 HDi | — | reported, not confirmed |
Two 406 with the same engine can carry different software, so match the numbers on the ECU label – HW 0281010877, PSA 9645532880 – and the software 1037353776 shown by your tool before ordering.
Archive contents
| File | Memory | Size |
|---|---|---|
0281010877_9645532880_SW1037353776_FLASH.bin | External flash | 524 288 bytes (512 KB) |
0281010877_9645532880_SW1037353776_EEPROM_1KB.bin | EEPROM 95080 | 1 024 bytes (1 KB) |
INFOS.html | Datasheet: references, vehicles, file list, checksums (12 languages) | – |
Both memories were read from the same box, so they match each other (including the donor’s immobiliser data). The MPC internal flash is not part of the archive: it is not needed to restore, clone or compare an EDC15C2 with the usual tools.
EDC15C2 0281010877 1037353776 ORI – references
| ECU | Bosch EDC15C2 |
| Bosch hardware (HW) | 0281010877 – printed 0 281 010 877 on the label |
| PSA part number | 9645532880 – printed 96 455 328 80 |
| Software (SW) | 1037353776 – also written SW1037353776 |
| Upgrade / SW upg. | none – your tool shows 1037353776 in both fields, or leaves the second one empty |
| Memory supplied | External flash 512 KB + EEPROM 95080 (1 KB) |
| Read method | Bench / BDM, complete read, file unmodified |
| Delivery | ZIP 400 KB, instant download after payment |
Professionals call this kind of file a full BDM backup or an ORI file – in French fichier d’origine, in Italian file ori.
Notes on this file
This page covers one exact software: EDC15C2 0281010877 with SW 1037353776. Another number on your tool means another file – use the search or ask us.
Compatible with KTAG, KESS3, Flex, Autotuner, bFlash, PCMflash, BDM100 and similar tools. However, in rare cases expect a quick alignment in a hex editor or WinOLS before you write the EDC15C2. For professional use – workshops and ECU technicians.
How to identify your ECU
On the label
The Bosch label on the EDC15C2 housing shows the hardware number 0 281 010 877 and the PSA number 96 455 328 80; it may also carry a Bosch sticker number starting with 1039S. That 1039S number is not the software: the software 1037353776 only appears when you read the ECU with a tool, or in the INFOS.html of this archive.
What KESS / KTAG show
| Field | What the tool shows |
|---|---|
| HW | often empty – use the label |
| SW | 1037353776 |
| SW upg. (SW màj., soft up, UpgSW) | empty, or 1037353776 again |
Expected ID screen: SW 1037353776, upgrade field empty or identical. Anything else in the upgrade field → not this file, search the upgrade number instead.
Other files you may need
- Bosch EDC15C2 family: all EDC15C2 original files →
- Guides: ORI, virgin and full backup explained · ECU file types
Your tool shows another number? Ask for it – we read new references every week.
Questions about this file
Is EDC15C2 0281010877 1037353776 ORI a full BDM backup or only the flash?
Full backup: the 512 KB external flash and the 95080 EEPROM were read together from the same ECU (Peugeot 406 2.2 HDi application) – enough to restore a bricked unit, clone it or start a stage 1 on 1037353776.
My tool shows SW 1037353776 but the HW field is empty. Right file?
Yes, KESS and KTAG often leave HW blank. Check 0 281 010 877 and 96 455 328 80 on the label; if the upgrade line is empty or repeats 1037353776, this is your file.
Will this file work on a Ford Mondeo?
Only if the Mondeo label reads HW 0281010877 / PSA 9645532880 and the tool shows 1037353776. It is reported with this software but we did not read it from a Mondeo ourselves.
Does the EEPROM contain the immobiliser of the donor 406?
Yes, as read. This is the original state of ECU 0281010877, not a virgin file: for another car, transfer your own immobiliser data or use a virgin EEPROM.
